The extensive range of 3 Way and 4 Way Valves offered by us is available in various models and technical specifications. These 3 way and 4-way valves are used to regulate the flow of liquids through a sequence of pipes. Our range is known for sturdy and abrasion resistant features, due to which these find application in numerous industrial applications.
(Other Models Foot Pedal Valve, Roller Valve, Disc Rotary Valve, Pilot - Pilot Valve)| SERIES 'S'- 3 Way (3 PORT) AND 4 WAY (5 PORT) HAND LEVER VALVE |
||
|---|---|---|
|
Technical specifications |
||
| Types | : | 2 Position & 3 Position , PHN, PRN, PAN. |
| Sizes | : | 11/4" BSP, 1/2" BSP, 3/4" BSP. |
| Pressure | : | 0 to 10 kg / cm2. |
| Media | : | AIR-Filtered and Lubricated. |
| Body Material | : | Powder coated Aluminium body. |
| (Other Models Foot Pedal Valve, Roller Valve, Disc Rotary Valve, Pilot - Pilot Valve)
|
||
| SERIES 'S'- 3 Way (3 PORT) AND 4 WAY (5 PORT) PUSH PULL VALVE/th> |
||
|---|---|---|
|
Technical specifications |
||
| Types | : | 2 Position & 3 Position , PHN, PRN, PAN. |
| Sizes | : | 1/4" BSP, 1/2" BSP, 3/4" BSP. |
| Pressure | : | 0 to 10 kg / cm2. |
| Media | : | AIR-Filtered and Lubricated. |
| Body Material | : | Powder coated Aluminium body. |
